Prüfen on PIN gesetzt ist:
AT+CPIN?
PIN Eingeben:
AT+CPIN=1234
Pin löschen:
AT+CLCK="SC",0,"1234"
Stick Status, zeigt Hersteller
ATI
|
1 2 3 4 5 6 |
ati Manufacturer: huawei Model: E173 Revision: 11.126.16.04.00 IMEI: 869878001234567 +GCAP: +CGSM,+DS,+ES |
Beispiel einer erfolgreichen Einwahl mit wvdail:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 |
# wvdial vodafone --> WvDial: Internet dialer version 1.61 --> Initializing modem. --> Sending: ATZ ATZ OK --> Sending: ATQ0 V1 E1 S0=0 &C1 &D2 +FCLASS=0 ATQ0 V1 E1 S0=0 &C1 &D2 +FCLASS=0 OK --> Sending: AT^SYSCFG=2,2,3FFFFFFF,2,4 AT^SYSCFG=2,2,3FFFFFFF,2,4 OK --> Modem initialized. --> Sending: ATM1L3DT*99# --> Waiting for carrier. ATM1L3DT*99# CONNECT --> Carrier detected. Starting PPP immediately. --> Starting pppd at Wed Mar 21 16:26:31 2018 --> Pid of pppd: 10192 --> Using interface ppp0 --> pppd: ▒[7f] --> pppd: ▒[7f] --> pppd: ▒[7f] --> pppd: ▒[7f] --> pppd: ▒[7f] --> pppd: ▒[7f] --> local IP address 100.76.134.164 --> pppd: ▒[7f] --> remote IP address 10.64.64.64 --> pppd: ▒[7f] --> primary DNS address 139.7.30.126 --> pppd: ▒[7f] --> secondary DNS address 139.7.30.125 --> pppd: ▒[7f] ^CCaught signal 2: Attempting to exit gracefully... --> Terminating on signal 15 --> pppd: ▒[7f] --> Connect time 4.3 minutes. --> pppd: ▒[7f] --> pppd: ▒[7f] --> pppd: ▒[7f] --> Disconnecting at Wed Mar 21 16:30:57 2018 |
/etc/wvdial.conf
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 |
[Dialer vodafone] Auto DNS = on Init1 = ATZ Init2 = ATQ0 V1 E1 S0=0 &C1 &D2 +FCLASS=0 Modem Type = Analog Modem ISDN = 0 New PPPD = yes Modem = /dev/ttyUSB4 Baud = 921600 [Dialer umts] Carrier Check = no Init4 = AT+CGDCONT=1,"IP","web.vodafone.de" Stupid Mode = 1 Phone = *99# Dialer Command = ATM1L3DT Dial Attemps = 2 [Dialer pin] Init3 = AT+CPIN=1234 [Dialer Defaults] Dial Command = ATM1L3DT Modem Type = Analog Modem Baud = 9600 Username = nyx Carrier Check = on Password = nyx Stupid Mode = on Check Def Route = on ISDN = 0 Abort on Busy = off Init3 AT+CGDCONT = 1,"IP","web.vodafone.de" Abort on No Dialtone = on Ask Password = off Init = ATZ Phone = *99# Init1 = ATZ Init2 = ATQ0 V1 E1 S0=0 &C1 &D2 +FCLASS=0 Init4 = AT^SYSCFG=2,2,3FFFFFFF,2,4 Auto Reconnect = on Init2 ATQ0 V1 E1 S0 = 0 &C1 &D2 +FCLASS=0 Auto DNS = on Idle Seconds = 0 Dial Attempts = 100 Modem = /dev/ttyUSB4 |
